Full-featured string controller for packs up to 1000 V and 600 series cells

6 safety rated contactor drives and pyroswitch output with safety rated redundant switching

Redundant pack voltage, current and isolation measurement

68 I/O, plus 3x CAN-FD, RS-485 and optional Ethernet

Designed to ISO 13849 PL d

Monitors and balances up to 16 series cells

High-current passive balancing, up to 1 A per cell

Redundant cell voltage measurement, ±2.25 mV lifetime accuracy

4 temperature inputs, or 2 redundant pairs

Wide 11 V to 80 V module supply

Bottom-side heatsinking to the pack for full balancing current

Compact cell monitor for up to 16 series cells, with up to 0.2 A balancing

Redundant cell voltage measurement, ±2.25 mV lifetime accuracy

4 temperature inputs, or 2 redundant pairs

Enhanced transient protection and a compact 100 × 67.5 mm footprint

Variants for 11 V to 36 V and 18.3 V to 70 V modules, plus busbar bypass

Monitors and balances 3 to 16 series cells, 10 V to 60 V

300 A continuous solid-state switching with secondary disconnect

Redundant cell voltage and temperature measurement

Parallel packs with automatic addressing

CAN or RS-485, plus fan, heater and expansion I/O
